KUN YOU Pharmatech Co.,LTD.
Manufacture the best softgel capsule /paintball machine for you！
|Place of Origin:||China,Beijing|
|Minimum Order Quantity:||1 set|
|Price:||USD 1-10000 per set|
|Packaging Details:||Wood cages|
|Delivery Time:||8 work days|
|Payment Terms:||T/T， L/C, Western Union|
|Supply Ability:||1000 sets per year|
|Material:||Stainless Steel||Application:||Softgel Capsule|
|Capacity:||60-1500L||Fuction:||Mixer And Melter|
|Name:||Industrial Jacketed Pressure Gelatin Melting Tank With Stirrer|
stainless steel tanks
The gelatin melting and service tank is used to melting the gelatin and keep the gelatin mass at a desired temperature and supply the gelatin to the encapsulation machine. We have both gravity feeding tank and pressure feeding tank. The plug and socket is IP65 grade make it easier to clean the tank.
The gelatin service tank is used to keep the gelatin mass at a desired temperature and supply the gelatin to the encapsulation machine. We have both gravity feeding tank and pressure feeding tank. The plug and socket is IP65 grade make the tank easier to be cleaned.
The gelatin service tank is used to keep the gelatin mass at a desired temperature and supply the gelatin to the encapsulation. We
have both gravity feeding tank and pressure feeding tank. The plug and the socket is IP65 grade make the tank easier to be cleaned.
Structure: Three layered water bathe
Material: SUS304,Medicine contacting parts SUS316
Standard: GB150-1998 and GMP
Max vaccum: <-0.09 MPa
Oening : Gel inlet 160*130mm, View glass φ60mm
Hydraulic lift range: 500mm
Gelatin discharge: Upper outlet
Temperature sensor: bottom RTD sensor
Power: 380V/240V 50/60Hz 7.5kW
1.Water bath type gelatin tank is a special equipment for melting gelatin and production process.
2.The gelatin melting tank has the advantage of compact structure, stable transmission and stable running performance.
3.The mixing/stirring process is operated through connecting loop coupling and is composed of plurality of split agitator with stable transmission and better homogenization effect. The whole body of the tank is made of stainless steel.
4.The body include three layers, including the tank liner, heating jacket and heat preservation layer.
5.Heating the inner of the tank with the circulation hot water, it will be featured by fast heating, good thermal insulation performance, improving the quality of gelatin, accelerating the gelatin melting and shorten the melting time.
6.The liner is closed totally with very good vacuum performance.
7.The feeding mouth is convenient o assemble and repair. The whole tank is very smooth and bright with features of convenient cleaning, anti-corrosion and anti-acid, etc. Gelatin melting tank adopts stainless steel construction for its whole body.
8.During its working process, the machine will suck moisture from inside of the tank, leaving the vacuum. All these are in accordance with the requirement of GMP. So the gelatin melting tank is an ideal equipment for the soft capsule pharmaceutical line.
with the tank or septate on the wall
Q1:Are you factory or trading company?
A: We are factory and manufacture.
Q2: Where is your factory located? How can I visit your factory?
A: We are located in Beijing, you can fly to Beijing airport or Nanyuan airport. Wecan pick you up from the airport or your hotel.Welcome to visit us!
Q3:How to place my order?
A: Just contact us via TraderManager, E-mail, Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
Q4 : What is the payment term?
A: 30% T/T deposit and 70% T/T balance payment before shipping.
Q5:How long is the delivery time?
A: About 3-7 working days.
