S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer

S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer

S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer
video
S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer
Product Details:
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T, L/C
Supply Ability: 30 Set/Sets
Contact Now
Detailed Product Description
Type: Encapsulation Machine Application: Capsule,Chemical
After-sales Service Provided: Engineers Available To Service Machinery Overseas Warranty: 1 Year
Voltage: 380/220 Condition: New
Automatic Grade: Automatic Driven Type: Electric + Pneumatic
High Light:

soft gel encapsulation machine

,

capsule maker machine





Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel







Quick Detail



Overall Dimension

1250×400×2300mm

Driven Type

Electric

Capacity

22800 pcs/hour, 4r/min

Material

Stinless Steel

Application

Food, pharmaceutical,softgel making machine

Capsule shape

OV, OB,etc



Product Description



S403 R&D soft capsule making machine conform to the requirements of GMP standard. It is simple and efficient laboratory machine especially for R&D or small scale soft capsule production in laboratories and pharmaceutical researcging institutes.



The whole set of the equipment is simple and efficient with small occupation. It includes the gelatin melting system, fill material system, soft capsule encapsulation machine and tumbler drying machine. All the material for the whole set of the equipment are well selected to meet the requirements of GMP, making it applicable for medical, food and cosmetic industries.



S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer 0



Applications:


It's widely used in pharmaceutical industries, cosmetic and food industries.



Specification



Model

S403

Die roll size

Ф80X100mm

Die roll speed

0~5rpm

Overall dimension

1250×400×2300mm

weight

600kg

Power supply

380V/240V,50/60HZ

Power of the main motor

1.1kw

Power of the main machine

3kw





S403 R&D softgel encapsulation machine

Shape

Capsules/hour

2r/min

3r/min

4r/min

5#OV

12600

18900

25200

8#OV

11400

17100

22800

10#OV

8640

12960

17280

11#OB

7200

10800

14400

16#OB

6840

10260

13680

20#OB

6480

9720

12960

24#OB

6120

9180

12240

Paintball

7200

10800

14400

6#round

14280

21420

28560









































Competitive Advantage:



1. Filling Tolerance<±1.5%

2. Easy to operate and clean

3. Die roll speed:0~5rpm, steplessly adjustable

4. Small load difference

5. Gelatin ribbon micro lubrication system



Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment



S403 Soft Gelatin Capsules Soft Capsule Making Machine WITH Stinless Steel convoyer 1

Large Scale Soft Gelatin Encapsulation Machine For Pharmaceutical Industry Use And Meet GMP Requirement





Large Scale Soft Gelatin Encapsulation Machine For Pharmaceutical Industry Use Meet GMP Requirement





Finished Products



Company Information

Beijing Kun You Pharmatech Co., Ltd. devotes itself to manufacture softgel encapsulation line, tumble dryer, softgel mould, softgel sorting machine, softgel auxiliary equipment, paintball production line, and related technique R&D.

We also accumulated rich experience of softgel encapsulation technique. We have many sets of high-precision CNC and auxiliary equipments, and our professional design, technology, production and service personnel, enable us to produce high performance equipment, mould and top quality service. We are not only a equipment and mould supplier, but also a turn-key solution and formula provider.Easpcially in veggie gel capsule.

Kun You is keeping good cooperation relationship with companies from USA,Swissland, Germany, Canada, Russia, Mexcio, Vietnam, Turkey, Brasil, India, etc., in the meantime, our products and service have been exported to those regions too.
