Product Details:
Place of Origin: China,Beijing
Brand Name: Kunyou
Model Number: TD-3
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wood cages
Delivery Time: 30-60 days
Payment Terms: T/T, L/C, Western Union
Contact Now
Detailed Product Description
Certification: ISO CE Application: Capsule,paintball
After-sales Service Provided: Engineers Available To Service Machinery Overseas Capacity: 100L-20T
Material: 304/316L Stainless Steel Warranty: 1 Year
High Light:

soft gel capsule machine

,

soft gelatin capsule machine



0.75kw Automatic Encapsulation Machine With Tumble dryer For Pharmaceutical





Quick Detail



Product Name

 Tumble Drying Machine/ Tumble Dryer

Power consumption

0.75kw

Drying fan Motor(KW)

0.55KW

Basket per section

1

Application

Drying softgel/paintball or pills or fish oils,etc









Product Description



TD-3 Soft Capsule (Softgel) and paintball Tumble dryer is used to predry and initial shaping of soft capsule (softgel) and paintballs. TD-3 Soft Capsule (Softgel) and paintball Tumble dryer is the largest domestic drying tumble currently. Each section is provided with two large air blowers. The organic glass cover of TD-3 Soft Capsule (Softgel) and paintball Tumble dryer can be opened with safety protection. The standard configuration is 8 sections. Each section is equipped with an independent fan to make softgels and paintballs distribute evenly, thus making the drying effect much better. Each dryer can be easily removed and easy to clean, so it’s more in line with the requirements of GMP. Each dryer is equipped with electrostatic guiding device and safety production device. The operator can conveniently make the dryer stop just in the tumble dryer position. TD-3 has advanced structure and stable material, making its drying effect much better than other models of domestic and Korean machine.





Application



1. TD-3 Soft Capsule (Softgel) and paintball Tumble dryer is used to predry and initial shaping of soft capsule (softgel) and paintballs.
2. It’s for pharmaceutical enterprises, health care products, cosmetics and paintball production line.

0.75kw Automatic Vgel Encapsulation Machine With Tumble dryer machine with 2 drying fan 0


Specification



Model

TD-3

Basket diameter(mm)

730

Basket length(mm)

1010

Weight (ton)

2ton

Drying fan(kw)

0.55

Motor Power(kw)

0.75

Basket per section

1







Competitive Advantage



1. The largest domestic drying tumble

2. Two large air blowers in each cage

3. Each cage can regulate speed separately

4. Safety protection device



drying tumbler for soft capsule, drying tumbler for paintballs, soft capsule dryer, paintball dryer, paintball drying machine, soft capsule /softgel drying machine

0.75kw Automatic Vgel Encapsulation Machine With Tumble dryer machine with 2 drying fan 1
0.75kw Automatic Vgel Encapsulation Machine With Tumble dryer machine with 2 drying fan 2
