Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel

Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel

  • Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel
Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel
Product Details:
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T, L/C
Supply Ability: 30 Set/Sets
Contact Now
Detailed Product Description
High Light:

soft gel encapsulation machine

,

automatic capsule filling machine



Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel





Quick Detail



Overall Dimension

1250×400×2300mm

Driven Type

Electric

Capacity

22800 pcs/hour, 4r/min

Material

Stinless Steel

Application

Food, pharmaceutical,softgel making machine

Capsule shape

OV, OB,etc





Product Description



S403 soft capsule making machine is specially for laborotary and small scale production. It's elaborately designed strictly according to the requirements of GMP. The whole set of the manufacturing line is simple but efficient with a small space. In the manufacturing line, including a main machine, control system, water cooling system, lubrication oil saving system, a set of tumble dryer, one set of die roll and KUN YOU gelatin reactor. All the spare parts or other material are selected according to the requirements of GMP.



Thus making it applicable for pharmaceutical, nutrition food and cosmetic industries.



Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel 0



Applications:


It's widely used in pharmaceutical industries, cosmetic and food industries.



Specification



Model

S403

Die roll size

Ф80X100mm

Die roll speed

0~5rpm

Overall dimension

1250×400×2300mm

weight

600kg

Power supply

380V/240V,50/60HZ

Power of the main motor

1.1kw

Power of the main machine

3kw





S403 R&D softgel encapsulation machine

Shape

Capsules/hour

2r/min

3r/min

4r/min

5#OV

12600

18900

25200

8#OV

11400

17100

22800

10#OV

8640

12960

17280

11#OB

7200

10800

14400

16#OB

6840

10260

13680

20#OB

6480

9720

12960

24#OB

6120

9180

12240

Paintball

7200

10800

14400

6#round

14280

21420

28560









































Competitive Advantage:



1. Filling Tolerance<±1.5%

2. Easy to operate and clean

3. Die roll speed:0~5rpm, steplessly adjustable

4. Small load difference

5. Gelatin ribbon micro lubrication system



Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment



Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel 1Laboratory Electric Soft Capsule Making Machine Small Scale Stainless Steel 2
