KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer

KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer

    • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer
    • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer
    • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer
    • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer
    • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer
  • KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer

    Product Details:

    Place of Origin: China,Beijing
    Brand Name: Kunyou
    Certification: CE,ISO9001
    Model Number: KSM-8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Wood cages
    Delivery Time: 30-90 days
    Payment Terms: T/T, L/C
    Supply Ability: 15 Set/Sets per year
    Contact Now
    Detailed Product Description
    Material: SS304/316 Capacity: 300,000-400,000capsule Per Hour
    Roller: 6-8 Converyer: Avaliable
    Control: PLC Warantee: 1 Year
    High Light:

    capsule counter machine

    ,

    capsule sorter

    Stainless Steel Capsule sorting Inspection Machine



    Quick Detail



    Product Name

    Soft capsule /Pill sorting machine

    Brand Name

    KUN YOU

    Application

    Softgel /Soft capsule manufacturers

    Model

    KSM-8

    Material

    304 SUS

    Capacity

    Max 400000



    Product Description



    The automatic sorting machine is used to sort softgel capsules. It’s suitable for sorting round, oblong, oval, tube shape capsules. Soft capsule with unqualified geometry will be eliminated by adjusting the distance between the separation rollers. It’s suitable for sorting the softgel which is spherical, cylindrical, oval, tubular rotary body shape. Soft capsule sorting machine can be used in the pharmaceutical, health food, cosmetics, paintball industry soft capsule products. It also can be suitable for sorting paintball, pills and tablets, etc. KSM-8 sorting machine has 8 sorting rollers.



    KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer 0

    Beijing Kun You Pharmatech Co., Ltd not only supply and sell the soft capsule sorting machine but also provide the price inquiry and after-sale service.

    Application


    It’s mainly used in the pharmaceutical, health foods, cosmetics and paintball industry soft capsule products. It can also be used for the screening of paintballs, pills and tablets.

    KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer 1
    Specification



    Model

    KSM-8

    Sorting Roller Qty.

    8 Paris

    Capacity (pcs/hour)

    Max 400,000

    Precision

    ±0.1mm

    Sorting limit size

    0-25mm

    Dimension

    1650×1150×1750

    Power consumption

    0.5kw

    Power supply

    220v/380v/415v   50Hz/60Hz



    Competitive Advantages



    1. It’ s convenient to adjust the roller distance

    2. Low energy consumption, saving energy

    3. Conveyor belt to transport pills and we also have vibrating to transport capsules

    4. Low noise and enviorment friendly

    5.High Accuraturion with ball screw agjustment

    6. PLC control for the gap of the roller

    7.Angle of the roller with ground is adjustable

    8.The length of the big/Small size of the convyer both agjustable

    9.Famous Brand for the Viberation and the bearing

    10. From 4-8 roller to choose for different capacity



    Sorting machine for tablets,Sorting equipment, Sorting capsules for pharmaceutical,

    Sorting paintballs.





    KY Paintball / Capsule Size And Shape Sorting Capsule Inspection Machine With Converyer 2
