Precise Paintball Making Machine / Encapsulation Machine With Drum Design

Precise Paintball Making Machine / Encapsulation Machine With Drum Design

    • Precise Paintball Making Machine / Encapsulation Machine With Drum Design
    • Precise Paintball Making Machine / Encapsulation Machine With Drum Design
    • Precise Paintball Making Machine / Encapsulation Machine With Drum Design
  • Precise Paintball Making Machine / Encapsulation Machine With Drum Design

    Product Details:

    Place of Origin: China,Beijing
    Brand Name: Kunyou
    Certification: CE,ISO9001
    Model Number: S406PB

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Wood cages
    Delivery Time: 20-60 days
    Payment Terms: T/T, L/C
    Supply Ability: 30 Set/Sets Per Year
    Contact Now
    Detailed Product Description
    High Light:

    paintball manufacturing machine

    ,

    paintball production line





    Precise Paintball Making Machine / Encapsulation Machine With Drum Design



    Quick Detail



    Product Name

    Paintball Making Machine

    Material

    Stainless Steel

    Port

    FOB Tianjin

    Power Consumption

    7 kw

    Scale

    Medium Scale Production

    Capacity

    18000pcs/hour



    Product Description



    Our company is the first in China to export paintball equipment to North America which is capable of making tournament grade paintball, still the biggest paintball machine maker in China. Compared with the softgel machine, the paintball making need better machine accuracy, the drive transmission system is also percisionly improved. The ancillay are also modified correspondingly. The hopper and spreader box adopt level switch, making the level control more precise. Besides, the injection wedge, spreader box and hopper adopt the design of precise PID temperature control . The micro lubrication system largely reduce the consumption of paraffin oil.


    S406 paintball Encapsulation Machine considers the need and the biggest benefits of customers as start point, combining advantages of foreign equipment and requirements of customers. S406 Paintball Encapsulation Machine’s die roll is 152 mm long. The die roll’s rotation rate can be regulated within 0 to 5 rpm, so users can choose the most appropriate speed according to different materials and process parameters. S406 Paintball Encapsulation Machine improves the bearing spindle supporting way of die roll, thus making the spindle more accuracy and much easier to repair. In addition, the machine further improves the machining precision. More helical gears are used in the process of gear moving, which improve the gear coincidence degree and transmission stability. The split structure of cooling fan reduces the thermal effect to the pressure pill. Besides, gelatin barrel is added with wheel which can be moved more conveniently and easily. The machine is provided with stirring or insulation optional hopper, using ground automatic feeding method. The paintball machine’s oil roller is made of stainless steel material, so it’s more in line with the requirements of GMP.

    Specification


    Model

    S406PB

    Die roll diameter

    Ф103mm

    Die roll length

    152mm

    Die roll speed

    0~5rpm

    Plunger numbers

    10

    dimension

    880X640X1900mm

    weight

    900kg

    Power consumption

    7 kw

    Control mode

    PLC+HMI Switch/buttons

    Output rate

    18000 pcs/hour




    Competitive Advantages



    1. Good stability
    2. Adjustable rotation rate during 0-5rpm
    3. Easy to operate and clean, conforming to GMP
    4. Compact and beautiful
    5. It can be assembled or disassembled with single hand
    6. Big air flow
    7. Reduce the oil consumption
    8. The cable plug has good waterproof and oil proof function
    9. High technical loading capacity
    10. High precision
    11. Easy to move and operate
    12. Drum design to prevent gelatin wrinkling and sideship
    13. Professional PID temperature control technology is adopted on the machine, temperature of injector can be adjusted accurately. Improves ratio of finished products of paintball.



    Paintball Making Equipment, Paintball Manufacturing Line, Various Model Die Roll For Soft capsule and Paintball and All kinds of spare parts for softgel making machine and paintball making machine. Professional Technicians and years of operation, welcome to inquire!
