7 Inch 13 Kw 220V/380V PLC Control Softgel Encapsulation Machine for Medical Applications

1 set
MOQ
7 Inch 13 Kw 220V/380V PLC Control Softgel Encapsulation Machine for Medical Applications
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Medical
Type: Filling Machine
Condition: New
Voltage: 220V/380V
Driven Type: Electric
Warranty: 1 Year
Highlight:

capsule making machine

,

7 Inch Capsule Filling Machine
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S407
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 60-90 days
Payment Terms: T/T， L/C
Supply Ability: 30 Set/Sets Per Year
Product Description
7 Inch Capsule Filling Machine
Product Overview
13 Kw PLC Control Pharmaceutical Machinery For Softgel Capsule Production Line
Product Name Soft capsule making machine
Power consumption 13 kw
Control Mode PLC+Touch screen
Plunger Numbers 12
Dimension 880X2200X2000mm
Dosage deviation < ±2%
Product Description
The S407 Softgel Encapsulation Machine is an advanced model developed from the S406, featuring a 20mm longer die roll. Designed with customer needs as the priority, it combines international equipment advantages with practical functionality.
7 Inch 13 Kw 220V/380V PLC Control Softgel Encapsulation Machine for Medical Applications 0
Key Features
  • Dosage deviation: < ±2%
  • Material of oil roller: porous stainless steel
  • Parallel degree of main shaft of the die rolls: <0.02mm
  • Micro gelatin ribbon oil lubrication
  • Precision temperature control for injection wedge, spreader box and chilled water
  • Running parameters can be stored and recalled with touch screen operation
  • Pneumatic wedge lift up
  • Pneumatic left die shaft movement
Applications
Ideal for softgel manufacturing enterprises, pharmaceutical companies, and research universities.
Technical Specifications
Model S407
Die roll Ф103X172mm
Die roll speed 0~7rpm
Plunger numbers 12
Overall dimension 880X2200X2000mm
Weight 1200kg
Power consumption 13 kw
Control mode PLC+Touch Screen
Output rate 8#OV 50000-70000 pcs/hour
Competitive Advantages
  • PLC operation with touch screen interface
  • Significantly improved production efficiency
  • Adjustable rotation rate (0-7rpm)
  • Compact and ergonomic design
  • Easy single-hand assembly/disassembly
  • Reduced oil consumption
  • Separate or automatic adjustment capability
  • Built-in counting function for production monitoring
  • Data storage and recall functionality
  • Extended die roll life through pneumatic operation
  • Fault diagnosis and reminder system
  • Statistical reporting and printing capabilities
  • Enhanced safety features
  • Waterproof and oil-proof cable plugs
Manufacturer Advantages
  • Factory-direct competitive pricing
  • 20+ years of industry experience
  • Professional design and manufacturing team
  • Rigorous pre-shipment inspection
  • Extensive use of 316 stainless steel
  • Premium components (Siemens, Omron, Airtac, Mitsubishi, Schneider)
  • Comprehensive warranty coverage
Packing & Shipping
Machines are packed in wooden cases with softgel die rolls in standard boxes. Shipping is arranged via ocean freight through our logistics partners.
Services
We provide complete production line solutions including factory design, maintenance, spare parts supply, and technical support.
Company Information
Beijing KUN YOU Pharmatech Co., Ltd., established in 2008, specializes in pharmaceutical, food, and paintball machinery. With over a decade of innovation and collaboration with global partners, we offer advanced softgel encapsulation solutions including S406 (6"), S407 (7.5"), and S610 (10") models.
Our manufacturing facility features high-precision CNC milling machines, lathes, grinding machines, EDM, and wire cutting equipment, enabling us to produce state-of-the-art machinery and precision die rolls.
