Vegetable Gelatin Softgel Capsule Manufacturing Machine S610V Automatic Control
Product Description
The S610 Fish Oil Softgel Capsule Machine is a large-scale encapsulation system designed for high-volume production of softgel capsules containing oil liquids, suspension liquids, or pastes. This advanced machine features independent adjustable lubrication for reduced mechanical wear and synchronized operation between drug pump and capsule mold.
Key Features
- Independent motor-driven capsule brushes prevent gelatin from sticking in die roll cavities
- Separate lubrication system for medicine pump and die roll assembly
- Water-cooled drum with air blowers for efficient operation
- PLC and touch screen control with self-trouble diagnostic capabilities
- High-precision medicine pump with plunger diameter tolerance under 0.005mm
- Simple linear structure for easy installation and maintenance
- High-pressure double crank mechanism for precise die control
- GMP-compliant design with easy-to-clean components
Technical Specifications
| Model |
S610 |
| Power |
13.5KW |
| Die Roll Size |
150*250mm |
| Capacity |
12,000 capsules (8#OV@4rpm) |
| Dimensions |
2050*1200*1850mm |
| Speed Range |
0-7 rpm |
| Weight |
1900 kg |
| Plunger Volume |
2ml per stroke (20 plungers) |
| Control System |
PLC + Touch Screen |
Machine Components
- Micro Lubrication System
- Veggie Material Air Pressure Spreader Box
- PU Conveyor (easily replaceable)
- SS316 Hopper (Double Layer, customizable)
- Pump (Optional Ti or other material coatings)
Our Services
- Formula development support
- Factory layout design
- Custom spare parts manufacturing
- Technical consultation and support
- Factory tours and demonstrations
- Comprehensive machine installation and operation training
- Overseas engineering support
Packaging & Delivery
| Package Size |
Approximately 45 cubic meters for complete production line |
| Weight |
7 Tons |
| Packaging Details |
Standard wooden crate packaging (fumigated for European exports). Custom packaging options available based on container size and customer requirements. |
Company Information
Beijing KUN YOU Pharmatech Co., Ltd., established in 2008, specializes in designing, manufacturing, and selling pharmaceutical machinery, food machinery, and paintball machinery. With over a decade of experience and continuous technical innovation, we offer state-of-the-art soft capsule equipment and comprehensive production solutions. Our products are exported worldwide, including to the USA, Europe, and Asia. We provide complete production lines, turnkey projects, and technical know-how to meet diverse manufacturing needs.
Frequently Asked Questions
Q1: Are you factory or trading company?
A: We are the manufacturer with our own production facility.
Q2: Where is your factory located? How can I visit your factory?
A: Our factory is located in Beijing. We can arrange transportation from Beijing airport or your hotel for factory visits.
Q3: How to place my order?
A: Contact us via email, phone, or trade manager to confirm product details and make a 30% deposit payment to begin manufacturing.
Q4: What is the payment term?
A: Standard terms are 30% deposit with 70% balance payment before shipping.
Q5: How long is the delivery time?
A: Typical production and delivery time is 35-40 working days.
