Medical Soft Capsule Automatic Vgel Encapsulation system Machine For Vitamin / Fish Oil

1 set
MOQ
Medical Soft Capsule Automatic Vgel Encapsulation system Machine For Vitamin / Fish Oil
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Filling Equipment
Application: Capsule,Liquid
After-sales Service Provided: Engineers Available To Service Machinery Overseas
Capacity: 15000-21000grain/hour
Product Name: Encapsulation Machine
Certification: ISO CE
Warranty: 1 Year
State: Softgel Encapsulation Machine
Usage: Pharmaceutical,Cosmetics,Chinese Herb
Highlight:

capsule manufacturing machine

,

soft gel capsule machine
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403V
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T， L/C,Western Union
Supply Ability: 30 Set/Sets
Product Description
Medical Soft Capsule Automatic Encapsulation Machine / Vitamin , Fish Oil / PLC Control
Quick Detail
Product Name softgel automatic machine Driven Type Electric
Capacity 120000 Capsules / hour Max Material Stinless Steel
Application Food, pharmaceutical,softgel making machine Capsule shape OV, OB,etc
Applications:

It’s mainly for softgel and paintball making enterprises and pharmaceutical enterprises, especially for R&D department of laboratories, pharmaceutical factories in the universities and plant health products and Research Institutes.It also can suitable for cosmetic manufactures, such as bath beads and Collagen capsule.

Specification
Model S403 S406 S407 S610
Die roll diameter(mm) 80 103 103 150
Die roll length(mm) 100 152 172 250
Die roll speed 0-5rpm 0-5rpm 0-7rpm 0-5rpm
Plunger Qty. 6 10 12 20
Dimension 1450*600*1350 880*640*1900 800*2200*2000 2050*1200*1850
Weight(kg) 600 900 1200 1900
Power(kw) 3kw 7kw 13kw 20kw
control PLC.touch screen
Specifically speaking, it has the following characteristics:
  • Small size, low energy consumption
  • Dosage deviation:< ±2%
  • Material of oil roller: porous stainless steel
  • Parallel degree of main shaft of the die rolls:<0.02mm
  • Micro gelatin ribbon oil lubrication
  • Precision temperature control for injection wedge, spreader box and chilled water.
  • The running parameters can be stored and recalled with a finger tip touch if necessary.
  • Pneumatic wedge lift up.
  • Pneumatic left die shaft movement.
  • Important parts use aviation grade high wear-resisting material

Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment

Tag:

soft gelatin capsule machine

soft gel capsule machine

capsule manufacturing machine
