SS316/304 Starch Gelatin Melting Tank With Vacuum And Mix Paddle and platform

GMT800 The total height is the distance from discharge valve to the top of motor reducer. The height from base of supporting leg to discharge valve is smaller.

The GMT800 insulation ball valve made of special stainless steel is equipped at the discharge area.

• a) The GMT800 is manufactured and examined in compliance with JB2880-81
• b) . Standard of Welded steel Normal Pressure Container’. Vacuum degree in the vessel: 0.02-0.09 Mpa.
• c) Working pressure in the vessel: 0.03-0.05 Mpa.
• d) Examining Pressure in the vessel: 0.3-0.4 Mpa.
• e) Working pressure in the jacket: 0.03-0.098 Mpa
• f) Working temperature in tank: 50-100 ℃
• g) Conveyor granule: 30 CP
• h) Sealing parts and ring can used more than 3,000 hours continuous
• i) Insulating layer use super-fine glass cotton.
• j) Inner vessel and insulation layer (covered layer) of the tank, those sections exposed to raw material are made Of 1Cr18Ni9Ti stainless steel.
• k) The GMT and all stainless steel parts are well-polished
