13 Kw PLC Control Pharmaceutical Machinery For Softgel Capsule Production Line
Quick Detail
|
Product Name |
Soft capsule making machine |
Power consumption |
13 kw |
|
Control Mode |
PLC+Touch screen |
Plunger Numbers |
12 |
|
Dimension |
880X2200X2000mm |
Dosage deviation |
< ±2% |
Product Description
S407 Softgel Encapsulation Machine is developed based on Model S406 softgel encapsulation machine. The die roll length is 20mm longer. It combines advantages of foreign equipment and requirements of customers,considering the needs and the biggest benefits of customers as start point.There are following features besides S406’s. S407 adopts PLC operation, making operation more convenient. The die roll’s rotation rate can be regulated within 0 to 7 rpm, so users can choose the most proper rotation rate according to data of different material and techniques.
Drying cycle is controlled by PLC unified, so users can regulate the cycle time conveniently. The tumbler dryer is designed with a device to remind operators to prepare well when discharging. S407 can realize the function of statistical statements and printing. The machine drive system’s lubrication pump is droved by motor alone, which greatly improves the lubrication performance when main equipment operating at a very slow speed. At the same time, it can reduce machine vibration, prolong machine overhaul time and save investment for users.
|
Model |
S407 |
|
Die roll |
Ф103X172mm |
|
Die roll speed |
0~7rpm |
|
Plunger numbers |
12 |
|
Overall dimension |
880X2200X2000mm |
|
weight |
1200kg |
|
Power consumption |
13 kw |
|
Control mode |
PLC+Touch Screen |
|
Output rate |
8#OV 50000-70000 pcs/hour |
Competitive Advantage
What is the advantages of Automatic Paintball/Softgel making machine ?
1)We are factory, direct sales with competive price;
2)More than 20 years experience;
3)Professional designer and worker to serve you;
4)This machine with a strict inspection before out of storage;
5)This machine use a large number of 316 stainless steel;
6)This machine use world famous electrical and pneumatic components,such as Siemens, omorn ,Airtac, Mitsubish, Schneider etc.
7)Within Warranty period, if under the usage of instruction sheet, any product broken or damage, we will offer the repair service for free or replace for free.
Packing&Shipping
We pack the whole machine with wooden case and pack the softgel die roll and paintball die roll with standard boxes.
We ship the whole line of macine by ocean through the freight agent.
Our services
We not only provide the whole paintball & softgel making machine line, but also can provide the factory design for you. In terms of the after-service, we will be responsible for such services as belows: maintenance, parts supplying, technical support.
Company Information
Beijing KUN YOU Pharmatech Co., Ltd., which is established in 2008, has been focusing on designing, manufacturing and selling pharmaceutical machinery, food machinery and paintball machinery.
KUN YOU Pharmatech provides various models of Softgel Encapsulation Machines (soft capsule encapsulation machine, paintball machine, soft gelatin capsule machine), such as S406 with 6" dies, the medium size S407 with 7.5" dies and the latest and largest S610 with 10"dies. Here, you can find whatever paintballs and soft capsules that you need. Welcome to Beijing KUN YOU Pharmatech Co., Ltd. We look forward to cooperating with you!
After more than ten years of unremitting efforts, our continuing research and cooperation with many domestic and foreign pharmaceutical factory, plant health products and paintball production factory, not only enable us to make a lot of technical innovation in soft capsule equipment, but also to accumulate rich experience in the production process of soft capsule. We also have rich experience in softgel formulation and manufacturing process. We have three sets of high accuracy CNC milling machine, together with lathe, grinding machine, EDM machine, wire cutting machine, we can make state-of-the-art equipments and softgel die roll.
Product samples.
FAQ
Q1:Are you factory or trading company?
A: We are factory and manufacture.
Q2: Where is your factory located? How can I visit your factory?
A: We are located in Beijing, you can fly to Beijing airport or Nanyuan airport. Wecan pick you up from the airport or your hotel.Welcome to visit us!
Q3:How to place my order?
A: Just contact us via TraderManager, E-mail, Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
Q4 : What is the payment term?
A: 30% T/T deposit and 70% T/T balance payment before shipping.
Q5:How long is the delivery time?
A: About 35- 40 working days.
