| Place of Origin: | China,Beijing |
| Brand Name: | Kunyou |
| Certification: | CE,ISO9001 |
| Model Number: | NJP1200 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | Wood cages |
| Delivery Time: | 30-90 days |
| Payment Terms: | T/T， L/C, Western Union, Western Union, MoneyGram |
| Supply Ability: | 30 Set/Sets |
| Type: | Filling Machine | Name: | Hard Soft Gel Capsule Machine |
|---|---|---|---|
| Warranty: | 1 Year | Power: | 4-12Kw |
| Application: | Granules | Material: | SUS304/316L |
| High Light: | capsule filling equipment,automatic capsule machine |
||
NJP-1200 Automatic hard capsule filling machine
The process layout and design of the filling machine are up to date and optimization, and minimize the time that powder exposure in the air and possibility that the powder spills.
The working part of the filling machine isolates from outside to free from pollution, and is easily cleaned and disassembled.
According to the technique features of products, all parts that contact with medicine and capsules use stainless steel materials with high-quality which is smooth and even on the surface, and easy to clean and disinfect, moreover, it doesn’t cause adsorption and chemical reactions with products. It meets the correlative standards of Chinese GMP, EU and FDA.
With new and unique fully enclosed design, the lubricant that equipment uses doesn’t in contact with product so that the product doesn’t be polluted from oil.
All moving parts are made by CNC manufacturing center with high accuracy, small noise and wear, meeting Ergonomics standard.
| Equipment model, specifications | NJP-7500 Automatic hard capsule filling machine |
| 3800kg/1700×1220×2150mm | |
| Motor power | 13.5kw/AC 380V;50Hz |
| The highest production capacity | 450000pcs/h |
| filled with capsule models | 00#~5# safety capsules A ~ E |
| Capsules on the chances | ≥99.5% |
| Capacity difference |
300mg≤±3% (After granulation, 40 ~ 80 mesh particles after filling) |
| Compressed air | 0.09m3/min 0.3Mpa |
| Water requirements | Water ring vacuum pump distribution tank recycling, but also an external water |
| Vacuum degree | -0.02~-0.06 MPa |
| Water Flow | 250L/h |
| Intake /Drain pipe diameter | 20/27mm |
| Working temperature | 21℃±3℃ |
| Workplace height requirements | Artificial feeding≥2.6m,Vacuum loading≥2.8m |
| Working environment relative humidity | 40~55% |
| Displacement | 300m3/h |
| special function | Can increase the pellet filling device; powder collector function |
| Control System | Variable frequency stepless speed regulation, PLC control |
| Material | Direct contact with capsules and medicines are made of 304 and 316L quality stainless steel |
1. The appearance of the whole machine is beautiful, the process is accurate and easy to use.
2. Precision intermittent dividing box transmission, low noise structure.
3. It can be filled with 00 # capsule, and the filling rate is more than 99%.
4. Variable frequency speed regulation, PLC programming control, safe and simple operation
5. The device is suitable for filling western medicine powder with good fluidity and health-care product
Packing & Delivery
| Delivery Time: |
30 working days after prepayment. Destination port: the Port at your option |
| Term of Payment & Price valid until |
30% or 50%T/T deposit, before shipment and pay the balance . 60 days from offering date |
| Package | Standard Export Case sea, air or express worthy |
| Port of Shipment | Shanghai or any other sea port in China |
| Warranty | Guarantee 12 months since installation and no more 20 months after delivery. |
| Quality of Goods: |
100% brand new, manufactured in the year. Origin of Goods: China. |
