Home /Products/Gelatin Melting Tank/450L Gelatin Melting Tank with 7.5kw-12kw Motor

450L Gelatin Melting Tank with 7.5kw-12kw Motor

1 set
MOQ
450L Gelatin Melting Tank with 7.5kw-12kw Motor
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Gelatin Melting Tank
Function: Melting Tank,Multifunction
Working Temperature: 100 Degrees
Power Of Stirring Motor: 7.5kw-12Kw
Pressure: <0.9 Mpa
Type: Mixing Machine,vacuum,melting Tank
Highlight:

Starch Melting Tank

,

Paintball Gelatin Melting Tank
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: 450L
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 30 days
Payment Terms: T/T， L/C,Western Union
Supply Ability: 30 Set/Sets Per month
Product Description
Gelatin Starch Melting Tank
304 SUS Gelatin Melting Tank 450L
Product Name Gelatin Melting Tank Heating type Water-bath heating
Application Paintball / Soft capsule manufacturers Model 450L
Material 304 SUS Capacity 650L
Product Description

The gelatin reactor series is essential equipment for gelatin preparation, with capacities ranging from 450L to 1000L.

450L Gelatin Melting Tank with 7.5kw-12kw Motor 0
Main Technical Data
  • Vacuum degree in the vessel: 0.02-0.09 Mpa
  • Working pressure in the vessel: 0.03-0.05 Mpa
  • Examining Pressure in the vessel: 0.03-0.4 Mpa
  • Working pressure in the jacket: 0.03-0.098 Mpa
  • Working temperature in tank: 50-100 °C
  • Conveyor granule: 30 CP
  • Sealing parts and ring can be used more than 3,000 hours continuously
  • Insulating layer uses super-fine glass cotton
  • Inner vessel and insulation layer (covered layer) made of 1Cr18Ni9Ti stainless steel
Application

Primarily used by softgel and paintball manufacturers, this equipment is also essential for cosmetic producers (e.g., bath beads) and health product manufacturers creating various softgels.

Specification
Model 450L
Capacity(L) 650
Melting gelatin(L) 100-450
Heating area(M2) 3.2
Max degree of Vacuum(Mpa) 0.09
Max Temperature(℃) -100
Motor Power (KW) 4
Stirring speed (r/min) 50
Dimension (mm) Φ1210X1880
Competitive Advantage
  • Stainless steel construction with multi-layer stirrer
  • Soft capsule gelatin melting tank heated by circulated hot water
  • Water sealed vacuum pump system
  • Three stainless steel interlayers for precise temperature control
  • Specially designed paddle ensures quick agitation and uniform mixing
  • Easy installation and cleaning process
450L Gelatin Melting Tank with 7.5kw-12kw Motor 1

Also known as: Softgel Gelatin Melting Tank, Gelatin Service Tank, Paintball Gelatin Melting Tank
