Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material

Certification
Good quality Paintball Encapsulation Machine for sales
Good quality Paintball Encapsulation Machine for sales
I'm Online Chat Now

Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material

China Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier
Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material supplier

Large Image :  Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material

Product Details:

Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S406PB

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 50000USD-70000USD
Packaging Details: Wood cages
Delivery Time: 30-60 days
Payment Terms: T/T, L/C
Supply Ability: 30 Set/Sets Per Year
Contact Now
Detailed Product Description
Capacity: 180000 Paintball Per Hour Service: 1 Year Free
Warranty: Technion Avaliable Formula: Avaliable
Electric: Seimens And Schneider Carbler: As Requirement

18000P 7KW Paintball Production Line With PLC And Touch Screen

Quick Detail


Dimension

880X640X1900mm

Material

304 SUS

Port

FOB Tianjin

Power Consumption

7kw

Scale

Medium Scale Production

Capacity

18000pcs/hour


 Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material
Product Description


Our company is the first in China to export paintball equipment to North America which is capable of making tournament grade paintball, still the biggest paintball machine maker in China. Compared with the softgel machine, the paintball making need better machine accuracy, the drive transmission system is also percisionly improved. The ancillay are also modified correspondingly. The hopper and spreader box adopt level switch, making the level control more precise. Besides, the injection wedge, spreader box and hopper adopt the design of precise PID temperature control . The micro lubrication system largely reduce the consumption of paraffin oil.


S406PB paintball Encapsulation Machine considers the need and the biggest benefits of customers as start point, combining advantages of foreign equipment and requirements of customers. S406 Paintball Encapsulation Machine’s die roll is 152 mm long. The die roll’s rotation rate can be regulated within 0 to 5 rpm, so users can choose the most appropriate speed according to different materials and process parameters.


S406 Paintball Encapsulation Machine improves the bearing spindle supporting way of die roll, thus making the spindle more accuracy and much easier to repair. In addition, the machine further improves the machining precision. More helical gears are used in the process of gear moving, which improve the gear coincidence degree and transmission stability. The split structure of cooling fan reduces the thermal effect to the pressure pill. Besides, gelatin barrel is added with wheel which can be moved more conveniently and easily. The machine is provided with stirring or insulation optional hopper, using ground automatic feeding method. The paintball machine’s oil roller is made of stainless steel material, so it’s more in line with the requirements of GMP.

Paintball Samll Capacity Automatic Capsule Machine With Fromula / Raw Material
Specification


Model

S406PB

Die roll diameter

Ф103mm

Die roll length

152mm

Die roll speed

0~5rpm

Plunger numbers

10

dimension

880X640X1900mm

weight

900kg

Power consumption

7 kw

Control mode

PLC+HMI Switch/buttons

Output rate

18000pcs/hour



What is the specifications of Automatic paintball encapsulation machine ?

1)According to client's sepcial requirements, provides the special design such as oxgency pretection;

2)So many optional devices for clients to choose from R&D to big scale production.

3)Easy to operate, adopt advanced PLC from Germany Siemens, mate with touch and electric control system, the man-machine interface is friendly.

4)Frequency conversion adjusts the speed: this machine uses frequency conversion equipment, can be adjusted within the range according to the needs of reality in production.

5)Automatic checking: with servo motor ,the machine can run at 7rpm

6)Safty device: Machine stop at abnormal air pressure, heater disconnection alarm.

7)Main shaft parallelism is in 0.02mm

8)The die roll adjust and changment with clitch control ,save gelatin and time, easily operate

8)Use the Germany bearing; .

9)The shaft of the 2 rollers for die roll deviation is in 1.5%.

10)With Worm gear, the gear and shaft adopt special material with high accurary and long service life

11) Medicine hopper adopts thermial insulation design

12) Local language input in machine avaliable.

13)Micro lubrication

14). High quality and intelligence control system, PLC true color touch screen technology adopted by the electronic control system. All electric parts use world brand parts, such as Siemens, Schneider.

15) The hopper can keep medicine temperature steady, more suit to fill suspension into the paintball.

16) Air-cooling system is adopted at the output of paintball, that make paintballs amazing

17).Professional PID temperature control technology is adopted on the machine, temperature of injector can be adjusted accurately. Improves ratio of finished products of paintball.



Contact:
Vicky Rong
Sales Manager

Mobile/Whatsapp: 0086 177010269892
Skype: wicky.rong


Paintball Making Equipment, Paintball Manufacturing Line, Various Model Die Roll For Soft capsule and Paintball and All kinds of spare parts for softgel making machine and paintball making machine. Professional Technicians and years of operation, welcome to inquire!
