Home /Products/Gelatin Melting Tank/450L Gelatin Melting Tank with Water Bath Heating

450L Gelatin Melting Tank with Water Bath Heating

1 set
MOQ
450L Gelatin Melting Tank with Water Bath Heating
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Gealting Melting Tank
Production: Liquid And Gel
Mixer: Avaliable
Capacity: 300-1500L
Heating: Tem Conservation
Warranty: 1 Year
Highlight:

304 SUS Gelatin Melting Tank

,

450L Gelatin Melting Tank
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: GMT
Payment & Shipping Terms
Packaging Details: Wood cages
Payment Terms: T/T， L/C
Product Description
Water Bath Heating Gelatin Melting Tank
Product Overview
304 SUS Gelatin Melting Tank with Three Layers Of Water Bath Heating, 450L capacity.
Product Name Gelatin Melting Tank
Heating Type Water-bath heating
Application Paintball / Soft capsule manufacturers
Model 450L
Material 304 SUS
Capacity 650L
Product Description
The Series of gelatin reactor is the essential equipment in gelatin preparation. The Capacity is from 450L to 1000L.
450L Gelatin Melting Tank with Water Bath Heating 0
Main Technical Data
  • Vacuum degree in the vessel: 0.02-0.09 Mpa
  • Working pressure in the vessel: 0.03-0.05 Mpa
  • Examining Pressure in the vessel: 0.03-0.4 Mpa
  • Working pressure in the jacket: 0.03-0.098 Mpa
  • Working temperature in tank: 50-100 °C
  • Conveyor granule: 30 CP
  • Sealing parts and ring can used more than 3,000 hours continuously
  • Insulating layer use super-fine glass cotton
  • Inner vessel and insulation layer made of 1Cr18Ni9Ti stainless steel
Application
Primarily used by softgel and paintball manufacturers. Also essential for cosmetic manufacturers producing bath beads, and health product manufacturers creating various softgels.
Specification
Model 450L
Capacity (L) 650
Melting gelatin (L) 100-450
Heating area (M²) 3.2
Max degree of Vacuum (Mpa) 0.09
Max Temperature (℃) -100
Motor Power (KW) 4
Stirring speed (r/min) 50
Dimension (mm) Φ1210×1880
450L Gelatin Melting Tank with Water Bath Heating 1
Competitive Advantages
  • Stainless steel construction with multi-layer stirrer
  • Soft capsule gelatin melting tank heated by circulated hot water
  • Water sealed vacuum pump system
  • Three stainless steel interlayers for precise temperature control
  • Easy installation and cleaning
  • Specially designed paddle for quick and uniform mixing
  • Control system uses German electrical components
Softgel Gelatin Melting Tank, Gelatin Service Tank, Paintball Gelatin Melting Tank
