Stainless Steel Gelatin Color Mixer with Hydraulic Lifting System and 100-500L Capacity for Softgel Melting Tank

1 set
MOQ
USD 1-1000 per set
Price
Stainless Steel Gelatin Color Mixer with Hydraulic Lifting System and 100-500L Capacity for Softgel Melting Tank
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Stainless Steel
Capacity: 100-500Liters
Power: 13.5kw
Size: Big And Small
Fuction: Color Mixer
Warantee: 1 Year
Highlight:

mixing tanks with agitators

,

stainless mixing tank
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: CM-1
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 6 work days
Payment Terms: T/T， L/C
Supply Ability: 10000 sets per year
Product Description
Stainless Steel Softgel Melting Gelatin Color Mixer With Hydraulic Lifting System
Product Description
The CM-1 Color Mixer is designed for thorough mixing of color with gelatin in softgel production. This system combines a hydraulic lifting mechanism, mixing components, and electrical controls for optimal performance.
Operating Principle
The mixer inserts vertically into the vessel at the center position, with the stirrer head positioned at 1/3 depth from the bottom to liquid surface. This configuration ensures adequate space for material flow at the bottom of the vessel.
Key Features
  • Simple operation and cleaning with efficient, even color mixing
  • Special groove design minimizes foam and bubble formation during mixing
  • Hydraulic system allows precise positioning anywhere in the tank
  • Customizable to match specific tank size requirements
Technical Specifications
Dimension 1590×1200×2050(2950)mm
Speed Range 0-1,400 rpm (variable)
Weight 600kg
Total Power 13.5kW
Configuration ABB Motor
Panasonic Inverter
Fuji buttons
Siemens electrical components
SS316L material contact surfaces
SS304 machine housing
Warranty & Support
Includes one year free warranty service.
Manufactured by Beijing Kunyou Pharmatech Co Ltd
