Home /Products/Softgel Encapsulation Machine/Low Energy Consumption Stainless Steel Softgel Encapsulation Machine with 20000-120000 pcs/h Production Rate

Low Energy Consumption Stainless Steel Softgel Encapsulation Machine with 20000-120000 pcs/h Production Rate

1 set
MOQ
Low Energy Consumption Stainless Steel Softgel Encapsulation Machine with 20000-120000 pcs/h Production Rate
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Liquid
Type: Filling Equipment
Warranty: 1 Year
Control: PLC
Healthcare: Soft Gelatine Capsule
Operate Is Easy: Clean Is Convinent
Highlight:

Electric Softgel Encapsulation Machine

,

Softgel Capsule Machine
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S 403/S406/S610/S407
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T， L/C,Western Union
Supply Ability: 30 Set/Sets
Product Description
Soft Gel Medical Oil and Paste Filling Softgel Encapsulation Machine
Low energy consumption electric softgel encapsulation machine designed for food, pharmaceutical, and softgel production applications.
Quick Specifications
Product Name Softgel Encapsulation Machine
Driven Type Electric
Brand Name KUN YOU
Material Stainless Steel
Application Food, pharmaceutical, softgel making
Capsule Shape OV, OB, etc.
Production Description
Our professional softgel making machines are available in three models to accommodate different production scales:
Model S403 S406 S610
Production Capacity 20,000 pcs/hour 40,000 pcs/hour 120,000 pcs/hour
Application Small to large scale softgel production
We provide complete softgel production lines including gelatin melting systems, fill material systems, encapsulation machines, and drying machines. All equipment is constructed from high-quality stainless steel with premium brand components, featuring our proprietary gelatin ribbon micro lubrication system.
Applications
Ideal for softgel and paintball manufacturers, pharmaceutical companies, research laboratories, university facilities, and cosmetic producers (including bath beads and collagen capsule applications).
Technical Specifications
Model S403 S406 S407 S610
Die roll diameter (mm) 80 103 103 150
Die roll length (mm) 100 152 172 250
Die roll speed 0-5 0-5 0-7 0-5
Plunger quantity 6 10 12 20
Dimension (mm) 1450×600×1350 880×640×1900 800×2200×2000 2050×1200×1850
Weight (kg) 600 900 1200 1900
Power (kw) 2 7 13 20
Control system PLC with touch screen interface
Competitive Advantages
  • Compact design with low energy consumption
  • User-friendly operation and easy maintenance
  • High precision manufacturing
  • Minimal load variation
  • Advanced gelatin ribbon micro lubrication system
  • Critical components made from aviation-grade wear-resistant materials
Softgel making machine, Soft capsule making machine, Soft capsule encapsulation machine, Softgel machine, Soft capsule manufacturing machine, Softgel manufacturing machine, Softgel making equipment
Gelatin Melting Tank Specifications
Model 450L 600L 800L 1000L
Capacity (L) 650 900 1120 1370
Melting gelatin (L) 100-450 150-600 200-800 300-1000
Heating area (M²) 3.2 4 4.8 5.5
Max vacuum (Mpa) 0.09 0.09 0.09 0.09
Max temperature (°C) -100 -100 -100 -100
Motor power (KW) 4 5.5 7.5 7.5
Stirring speed (r/min) 50 50 50 50
Dimension (mm) Φ1210×1880 Φ1310×1980 Φ1410×2080 Φ1510×2130
We offer complete production lines for softgel and paintball manufacturing, including specialized die rolls, plastic drying trays, and transport trolleys.
