13kw Automatic Softgel Encapsulation Machine with 12 Plungers

1 set
MOQ
13kw Automatic Softgel Encapsulation Machine with 12 Plungers
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Liquid
Type: Softgel Capsule Machine
Warranty: 1 Year
Material: Stainless Steel
Pharma Gel: Cosmetic
Function: Making Soft Capsule
Highlight:

Soft Gelatin Encapsulation Machine

,

13kw Softgel Encapsulation Machine
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S407
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 60-90 days
Payment Terms: T/T， L/C,Western Union,MoneyGram,
Supply Ability: 30 Set/Sets Per Year
Product Description
13kw Classic Design Softgel Encapsulation Machine
Automatic liquid softgel encapsulation machine for fish oil, garlic oil, and vitamin filling applications.
Quick Specifications
Product Name Soft Capsule Filling Machine
Power Consumption 13 kw
Control Mode PLC + Touch Screen
Plunger Numbers 12
Dimension 880 × 2200 × 2000mm
Dosage Deviation < +2%
13kw Automatic Softgel Encapsulation Machine with 12 Plungers 0
Product Description
The S407 Softgel Encapsulation Machine is an advanced model developed from the S406, featuring a 20mm longer die roll. This industrial-grade machine combines international technology standards with practical customer requirements, offering superior performance and operational convenience.
Key Features
  • Precision dosage control with < +2% deviation
  • Porous stainless steel oil roller material
  • Main shaft parallel degree <0.02mm
  • Micro gelatin ribbon oil lubrication system
  • Precision temperature control for injection wedge, spreader box, and chilled water
  • Parameter storage and recall via touch screen
  • Pneumatic wedge lift and left die shaft movement
  • PLC-controlled drying cycle with adjustable timing
  • Motor-driven lubrication pump for improved performance
  • Tumbler dryer with discharge preparation reminder
  • Statistical statements and printing capability
Technical Specifications
Model S407
Die Roll Ф103 × 172mm
Die Roll Speed 0-7rpm
Output Rate 8#OV 50,000-70,000 pcs/hour
Weight 1200kg
13kw Automatic Softgel Encapsulation Machine with 12 Plungers 1
Competitive Advantages
  • Enhanced production efficiency
  • Compact, ergonomic design
  • Single-hand assembly/disassembly capability
  • Reduced oil consumption
  • Automatic or separate adjustment options
  • Integrated counting function for production tracking
  • Data storage and application system
  • Pneumatic operation extends die roll lifespan
  • Fault diagnosis and reminder system
  • Waterproof and oil-proof cable plugs
  • Improved safety features
Applications
Ideal for softgel manufacturing enterprises, pharmaceutical companies, and research universities requiring precision encapsulation solutions.
Soft capsule machine, softgel making machine, paintball making machine, tumble drying machine, gelatin melting tank
