Small Scale Fish Oil Vitamin Softgel Machines For Animal Gel And Starch

1 set
MOQ
Small Scale Fish Oil Vitamin Softgel Machines For Animal Gel And Starch
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Capsule
Type: Encapsulation Machine
Name: Soft Gel Capsule Machine
Warranty: 1 Year
Capacity: 4 Inch Die Roll Or 8 Inch Die Roll
Power: 4-12Kw
Roller Die Size: 80mm*100mm
High Light:

encapsulation softgel machines

,

small scale softgel machines

,

animal gel softgel machines

Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 30 Set/Sets
Product Description





R&D Softgel Encapsulation Machine For Oval Oblong Shape Fish Oil or Vitamin Softgel





Quick Detail



Product Name

S403 softgel automatic machine

Driven Type

Electric

Capacity

22800 pcs/hour, 4r/min

Material

Stainless Steel

Application

Food, pharmaceutical,softgel making machine

Capsule shape

OV, OB,etc

Small Scale Fish Oil Vitamin Softgel Machines For Animal Gel And Starch 0



Production Description



S403 R&D type softgel encapsulation machine/soft capsule machine is an experimental soft capsule machine designed especially for R&D department of laboratories, pharmaceutical factories in the universities and plant health products and Research Institutes.



Specifically speaking, it has the following characteristics:


Pneumatic die press system, pneumatic wedge up and down, independent driven capsule stripper.
Important parts use aviation grade high wear-resisting material
Main shaft run out and parellelism within 0.02mm
All bearing use well know brand
Medicine pump dosing deviation less than 1.5%
Worm gear, gear and shaft adopt special material with high accuracy and long service life
Gelatin ribbon micro lubrication system
Main shaft, mangle roller, colling drum driven by independent motor, speed controlled via frequency inverter.
Precision PID temperature control of the medicine hopper, injection wedge and spreader box.
Medicine hopper adopts thermal insulation design.
PLC and touch screen control, with functions of failure diagnosis.







Applications:


It’s mainly for softgel and paintball making enterprises and pharmaceutical enterprises, especially for R&D department of laboratories, pharmaceutical factories in the universities and plant health products and Research Institutes.It also can suitable for cosmetic manufactures, such as bath beads and Collagen capsule.





Specification



Model

S403

Die roll size

Ф80X100mm

Die roll speed

0~5rpm

Overall dimension

1250×400×2300mm

weight

600kg

Power supply

380V/240V,50/60HZ

Power of the main motor

1.1kw

Power of the main machine

3kw



Small Scale Fish Oil Vitamin Softgel Machines For Animal Gel And Starch 1

S403 R&D softgel encapsulation machine

Shape

Capsules/hour

2r/min

3r/min

4r/min

5#OV

12600

18900

25200

8#OV

11400

17100

22800

10#OV

8640

12960

17280

11#OB

7200

10800

14400

16#OB

6840

10260

13680

20#OB

6480

9720

12960

24#OB

6120

9180

12240

Paintball

7200

10800

14400

6#round

14280

21420

28560





































Small Scale Fish Oil Vitamin Softgel Machines For Animal Gel And Starch 2



Competitive Advantage:



1. PLC operation
2. Improve the efficiency of production largely
3. Adjustable rotation rate during 0-7rpm
4. Compact and beautiful
5. It can be assembled or disassembled with single hand
6. Reduce the oil consumption
7. Adjustable separately or automatically
8. The control system has a counting function to make operators get the number of pills clearly
9. Store and apply operating data
10. Lengthen the life of die roll by using pneumatic
11. Reminding and diagnosing faults function
12. Can realize the function of statistical statements and printing
13. More safety
14. The cable plug has good waterproof and oil proof function
