Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity

Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity

Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity
video
Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity
Product Details:
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 30 Set/Sets
Contact Now
Detailed Product Description
Type: Encapsulation Equipment Application: Capsule
After-sales Service Provided: Engineers Available To Service Machinery Overseas Warranty: 1 Year
Material: 304/316L Stainless Steel Capacity: 5800~120000 Pcs/ Hour
Usage: Pharmacy Or Other Relative Industries Reference Workshop Dimension: 60-500 Square
High Light:

encapsulation soft gelatin capsule machine

,

compact soft gelatin capsule machine

,

large capacity softgel making machine



Compact Pharmaceutical Machinery , Soft Capsule Encapsulation Machine





Quick Detail



Product Name

Soft Capsule Encapsulation Machine

Driven Type

Electric

Capacity

22800 pcs/hour, 4r/min

Material

Stainless Steel

Application

Food, pharmaceutical,softgel making machine

Capsule shape

OV, OB,etc



Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity 0

Production Description



S403 soft capsule making machine is specially for laborotary and small scale production. It's elaborately designed strictly according to the requirements of GMP. The whole set of the manufacturing line is simple but efficient with a small space. In the manufacturing line, including a main machine, control system, water cooling system, lubrication oil saving system, a set of tumble dryer, one set of die roll and KUN YOU gelatin reactor. All the spare parts or other material are selected according to the requirements of GMP.

This machine consist of soft capsule machine, sol pot, mould (die roll), capsule conveyor, tumbler dryer, cooling air machine, vacuum pump, drying tray, vacuum mixing barrel and electrical control system and other ancillary equipment.

This machine is the absorption of advanced technologies at home and abroad, based on a combination of soft capsule production process and the characteristics of the use advanced technology and high quality materials.

This machine cans all kinds of drugs, food, cosmetics, oils and hydrophobic substances in the quantitative suspension or paste injection pressure and encapsulated in gelatin membrane, the formation of various sizes in sealing the soft capsules.

Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity 1

Applications:


It's widely used in pharmaceutical industries, cosmetic and food industries.



Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity 2





Specification



Model

S403

Die roll size

Ф80X100mm

Die roll speed

0~5rpm

Overall dimension

1250×400×2300mm

weight

600kg

Power supply

380V/240V,50/60HZ

Power of the main motor

1.1kw

Power of the main machine

3kw





S403 R&D softgel encapsulation machine

Shape

Capsules/hour

2r/min

3r/min

4r/min

5#OV

12600

18900

25200

8#OV

11400

17100

22800

10#OV

8640

12960

17280

11#OB

7200

10800

14400

16#OB

6840

10260

13680

20#OB

6480

9720

12960

24#OB

6120

9180

12240

Paintball

7200

10800

14400

6#round

14280

21420

28560









































Competitive Advantage:



1. Small size, low energy consumption

2. Easy to operate and clean, automatic operation

3. High precision, 99.99% meet the requirement

4. Small load space ,60-100 square meters

5. Gelatin ribbon micro lubrication system

6. Important parts use aviation grade high wear-resisting material

7. Special design , die roll changes do not need to stop machine.

8. Fatory service, all parts are avaliable and special drsign.

9. Logo marked service.

10. Local language with machine touch screen.



Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment



Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity 3

Compact Encapsulation Soft Gelatin Capsule Machine Large Capacity 4
