CE Certificated Soft Gelatin Capsule Machine For Pharmaceutical Industry

1 set
MOQ
CE Certificated Soft Gelatin Capsule Machine For Pharmaceutical Industry
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Softgel Making Machine
Highlight:

soft gel encapsulation machine

,

capsule maker machine
Basic Infomation
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T， L/C
Supply Ability: 30 Set/Sets
Product Description
CE Certificated Soft Gelatin Capsule Machine For Pharmaceutical Industry
Quick Detail
Overall Dimension 1250×400×2300mm Driven Type Electric
Capacity 22800 pcs/hour, 4r/min Material Stinless Steel
Application Food, pharmaceutical,softgel making machine Capsule shape OV, OB,etc
Product Description

S403 R&D soft capsule making machine conform to the requirements of GMP standard. It is simple and efficient laboratory machine especially for R&D or small scale soft capsule production in laboratories and pharmaceutical researcging institutes.

The whole set of the equipment is simple and efficient with small occupation. It includes the gelatin melting system, fill material system, soft capsule encapsulation machine and tumbler drying machine. All the material for the whole set of the equipment are well selected to meet the requirements of GMP, making it applicable for medical, food and cosmetic industries.

Applications:

It's widely used in pharmaceutical industries, cosmetic and food industries.

Specification
Model S403
Die roll size Ф80X100mm
Die roll speed 0~5rpm
Overall dimension 1250×400×2300mm
weight 600kg
Power supply 380V/240V,50/60HZ
Power of the main motor 1.1kw
Power of the main machine 3kw
S403 R&D softgel encapsulation machine
Shape Capsules/hour
2r/min 3r/min 4r/min
5#OV 12600 18900 25200
8#OV 11400 17100 22800
10#OV 8640 12960 17280
11#OB 7200 10800 14400
16#OB 6840 10260 13680
20#OB 6480 9720 12960
24#OB 6120 9180 12240
Paintball 7200 10800 14400
6#round 14280 21420 28560
Competitive Advantage:
  1. Filling Tolerance<±1.5%
  2. Easy to operate and clean
  3. Die roll speed:0~5rpm, steplessly adjustable
  4. Small load difference
  5. Gelatin ribbon micro lubrication system

Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment
