SS316 Mold softgel capsule machine With Gelatin Melting And Drying system
Quick Detail
Product Name | softgel Encapsulation Machine | Driven Type | Electric |
Capacity | 120000pcs/hour Max | Material | Stinless Steel |
Application | Food, pharmaceutical,softgel making machine | Capsule shape | OV, OB,etc |
Production Description
Beijing Kun You Pharmatech Co., Ltd has four model for softgel/Capsule Making Machine, namely, S403,S406,S407 and S610. Among them, S403 is the smallest model for small scale or R&D research. And S610 is suitable for large scale production for soft capsule or paintball making, the production rate can get to 120000 capsules per hour or 32000 paintballs per hour. All these models are manufactured according to the requirements of GMP and many machinery parts are from famous brands, such as Schneider, Siemens. Besides, there are professional techinicians and leaders who are full of much experience in this line.
So far, our products have been exported to many countriesm, inclduing America, Canada, India, Iran and Mexico, etc. We aim at making the best soft capsule making machine for you and you make the best soft capsules or paintballs for consumers. That will be win-win. And this is what we want.
Welcome to Beijing Kun You Pharmatech Co., Ltd
Applications:
It’s mainly for softgel and paintball making enterprises and pharmaceutical enterprises, especially for R&D department of laboratories, pharmaceutical factories in the universities and plant health products and Research Institutes.It also can suitable for cosmetic manufactures, such as bath beads and Collagen capsule.
Specification
Model | S403 | S406 | S407 | S610 |
Die roll diameter(mm) | 80 | 103 | 103 | 150 |
Die roll length(mm) | 100 | 152 | 172 | 250 |
Die roll speed | 0-5 | 0-5 | 0-7 | 0-5 |
Plunger Qty. | 6 | 10 | 12 | 20 |
Dimension | 1450×600×1350 | 880×640×1900 | 800×2200×2000 | 2050×1200×1850 |
Weight(kg) | 600 | 900 | 1200 | 1900 |
Power(kw) | 2kw | 7kw | 13kw | 20kw |
control Mode | PLC.touch screen |
Competitive Advantage:
1. Small size, low energy consumption
2. Easy to operate and clean
3. High precision
4. Small load difference
5. Gelatin ribbon micro lubrication system
6. Important parts use aviation grade high wear-resisting material
