Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule

Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule

  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
  • Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule
Product Details:
Place of Origin: China,Beijing
Brand Name: Kunyou
Certification: CE,ISO9001
Model Number: S403
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wood cages
Delivery Time: 30-90 days
Payment Terms: T/T, L/C
Supply Ability: 30 Set/Sets
Contact Now
Detailed Product Description
Material: SS316 Service: Technion Avaliable
Die Roll Size: 80*100mms Capacity: 22800 Capsule/h
Certificate: CE Guarantee: 1 Year Free
High Light:

automatic capsule machine

,

softgel capsule machine





Laboratory Pharmaceutical Machinery For Softgel



Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule 0



S403 Softgel Encapsulation Machine







Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule 1 Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule 2





Productivity of Machine:







22,800 capsules/hour (8# OV, 4 RPM),



12,960 capsules/hour (20# OB, 4 RPM)





Function of Machine:







1.The gelatin ribbon is lubricated by micro lubricating technology to lower the consumption of



lubrication oil, the capsules are washing free and the drying time can be reduced remarkably.



2.The main moving parts adopt Swiss precise bearings. The gelatin ribbon drum assembly and mangle



roller are driven by independent motors, which are synchronized electronically. The noise is lowered



and it works more stable. By utilizing separate lubrication for medicine pump assembly and die roll



housing assembly, the waring is effectively reduced, which extends the failure-free operation time further.



3.Both medicine pump assembly and die roll are automatic synchronized. It is convenient to adjust the



occasion of injection.



4.Medicine pump adopts the new type of cam to avoid manual timing operation



5.The injection wedge can stop at any positon, making the operation more convenient and quick.



6.The wiring position of heating cables is more reasonable.



7.The frame is of Al ,easy to lift and stedy use.

8.PLC-based control, touch monitor interface or switch button interface can be selected. The control system



can complete trouble diagnosis and reserve interface for remote diagnosis to upgrade.



9.Temperature control material hopper, precise temperature control, auto liquid level control, it is suitable



to various kinds materials requirements.

10.

The temperature adjustable material hopper assembly is equipped with the standard configuration. And



it can stir material refill material automatically, alarm for shortage of medicine.







PLC:







Automatic Gelatin Level Control System:



Softgel Encapsulation Machine







Samples:

Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule 4







Packaging & Shipping







The Machine Line in Los Angeles in USA:



Quick Detail



Product Name

Soft Capsule Encapsulation Machine

Driven Type

Electric

Capacity

22800 pcs/hour, 4r/min

Material

Stinless Steel

Application

Food, pharmaceutical,softgel making machine

Capsule shape

OV, OB,etc





Production Description



S403 soft capsule making machine is specially for laborotary and small scale production. It's elaborately designed strictly according to the requirements of GMP. The whole set of the manufacturing line is simple but efficient with a small space. In the manufacturing line, including a main machine, control system, water cooling system, lubrication oil saving system, a set of tumble dryer, one set of die roll and KUN YOU gelatin reactor. All the spare parts or other material are selected according to the requirements of GMP.

This machine is the absorption of advanced technologies at home and abroad, based on a combination of soft capsule production process and the characteristics of the use advanced technology and high quality materials.

This machine consist of soft capsule machine, sol pot, mould (die roll), capsule conveyor, tumbler dryer, cooling air machine, vacuum pump, drying tray, vacuum mixing barrel and electrical control system and other ancillary equipment.

This machine cans all kinds of drugs, food, cosmetics, oils and hydrophobic substances in the quantitative suspension or paste injection pressure and encapsulated in gelatin membrane, the formation of various sizes in sealing the soft capsules.

This machine is widely used in laboratory, and small scale production.



Applications:


It's widely used in pharmaceutical industries, cosmetic and food industries.





Specification



Model

S403

Die roll size

Ф80X100mm

Die roll speed

0~5rpm

Overall dimension

1250×400×2300mm

weight

600kg

Power supply

380V/240V,50/60HZ

Power of the main motor

1.1kw

Power of the main machine

3kw





S403 R&D softgel encapsulation machine

Shape

Capsules/hour

2r/min

3r/min

4r/min

5#OV

12600

18900

25200

8#OV

11400

17100

22800

10#OV

8640

12960

17280

11#OB

7200

10800

14400

16#OB

6840

10260

13680

20#OB

6480

9720

12960

24#OB

6120

9180

12240

Paintball

7200

10800

14400

6#round

14280

21420

28560









































Competitive Advantage:



1. Small size, low energy consumption

2. Easy to operate and clean

3. High precision

4. Small load space

5. Gelatin ribbon micro lubrication system

6. Important parts use aviation grade high wear-resisting material



Softgel making machine,Soft capsule making machine,Soft capsule encapsulation machine,Softgel machine,Soft capsule manufacturing machine,Softgel manufacturing machine,Softgel making equipment

Laboratory Pharmaceutical Machinery For Softgel encapsulation machine oil and liquid capsule 5
