lab type softgel capsule filling machine , soft gelatin encapsulation machine for gels, serums, creams, pastes, oils
Application:
S403 soft gelatin encapsulation machine is mainly used for laboratory and drug research institutions capsule product development trial can be used as pharmaceutical, health care products factory, food factory test equipment. The machine features compact structure, complete functions, superior performance, compact structure, using a variety of automatic control technology, simple operation, stable performance, reliable work; the machine conforms to GMP standards. It is currently the smallest model experiment of soft capsule machine.
Main Specifications:
The cooling system with integrated cooling fan, low energy consumption, convenient installation, high precision of temperature.
The machine is compact and suitable for laboratory, low noise, high precision (loading error is less than 2%), to solve the problem with the waste of raw materials, the same raw materials can do more experiments.
This machine adopts 50HZ frequency control, rolling speed 0~2.5rpm, 2 single plunger feeding, the feeding amount of 0~3ml
Technical parameter
Technical parameter
| Die roll size |
80x100mm |
| Die roll speed |
0-5rpm |
| Charge for a single plunger |
0-3(ml) |
| Main motor power |
0.75kw |
| Machine Power supply |
1.5Kw |
| Power supply |
220V 50Hz |
| Over dimension |
1620x660x1350mm |
| Weight |
900kg |
Shape of Soft gelatin :
All shape like Round , Oval , Obong , Tube and so on, which all can be made as client's required.
Working processure;
Material preparation------>Gelatin colloid mill---->Gelatin melting----->Jacketed Gelatin storaging----->Hot water exchagner--->machine production-----> Tumble Dryer------> Product inspection------> Finished product
Complete line are including;
All of complete line of Soft Gelatin encapsulation line are including Main machine , Preparation tank, material tank, Gelatin melting tank, Gelatin storaging tank, Gelatine colloid mill, Hot water exchanger, Tumple dryer, Inspection table, gelatin pulverizer.
Our precision production room:
Packaging & Shipping
In Standard Wooden Case
60 working days after confirmed order
